Upgrade To Somfy Motor


  • Tubular motor 230 V/ 50Hz.
  • Integral manual over-ride system for use in the event of a power cut.
  • Manual over-ride ratio 27:1 with LT 50/ CSI and 55:1 with LT 60/ CSI.
  • The motor can be installed directly on the shutter endplate.
  • Series LT 50/ CSI fits in a tube with a minimum inner diameter of 47 mm. With the LT 60/ CSI that is 60 mm.
  • Limit switch capacity for LT50/ LT60: 34 revolutions.
  • Supplied as standard with a white 4-core (VVF) cable. 2.5 m long.
  • Compatible with all Somfy controls.


Technology: Wired Technology (WT)
Nominal Voltage / Frequency: 230V – 50Hz
Nominal Speed (rpm): 17
Nominal Torque (Nm): 25
Protection Index: IP 44
Basic crown for tube diameter (mm): 50 x 1.5
